WA76-D
Faithful Recreation Of The Fastest and Most Powerful "Rev-D" Studio Compressor With Added Recording Features.
The WA76-D accurately reproduces one of the fastest and most powerful studio compressors of all time known for ultra-fast dynamic control with rich analog tone. Added modern controls to achieve parallel compression, active & true-bypass, selectable input impedance, and sidechain flexibility make the WA76-D an ideal choice to balance modern workflows with vintage analog character.
_____
WA76-D återskapar exakt ljudkaraktären av den klassiska Rev-D kompressorn som är en av de snabbaste och mest älskade studiokompressorn genom tiderna. Känd för sitt generösa headroom, ultrarasnabba dynamiska kontroll och fylliga analoga ton. Med förstklassiga och specialtillverkade komponenter, såsom in- (O-12) och utgångs (5002) transformatorer från CineMag, uppnår WA76-D autentisk kompression i stil med klassiska 76 Rev-D som är känd för sitt "låga brus" i förstärkarsteget och den distinkta analoga karaktären. Moderna funktioner har lagts till så som parallellkompression, aktivt och true-bypass, samt variabel sidechain-filtrering, vilket gör WA76-D till ett perfekt val för den moderna inspelningstudion.
_____
The WA76-D accurately reproduces one of the fastest and most powerful studio compressors of all time known for its generous headroom, ultra-fast dynamic control, and rich analog tone. Using premium and custom components like O-12 (input) and 5002 (output) transformers from CineMag, WA76-D achieves authentic 76 rev-D style compression, known for having a "low noise" preamp stage with unmistakably analog character. Added modern controls to achieve parallel compression, active & true-bypass, selectable input impedance, and sidechain flexibility make WA76-D an ideal choice for modern recording workflows that require vintage tone shaping. WA76-D recreates the legendary tone & control of the vintage 76-style compression used in studios by artists like Chris Lord-Alge, Missy Elliot, Timbaland, Van Halen, Rick Rubin, Daft Punk, and many more.
Classic Studio Compression With Rich Analog Tone:
The WA76-D is a faithful recreation of the vintage 76 "Revision-D-style" FET studio compressor with added features to meet modern recording workflows. Recreating the lauded "D-style" version of the 76 compressor known for its speed, lower noise, and rich analog tone, the WA76-D offers the ideal blend of vintage circuitry and modern controls to deliver ultimate flexibility without sacrificing vintage analog character.
Critical Classic Controls + Bonus Modern Add-Ons:
WA76-D delivers vintage circuit design and all of the traditional 76-style compression controls; attack, release, ratio, input, output, and meter display. In addition to the classic controls expected on a 76-style compressor, WA76-D has added stereo linking, dry/wet mix for parallel compression, external sidechain, selectable input impedance, active & true-bypass, and a variable sidechain high-pass filter to tackle unruly bass that dominates the compressor’s attention.
Custom CineMag Transformers:
Just like in the vintage 76-style compressors from revision "A" to D", the WA76-D uses custom large-core, CineMag input & output transformers. The transformers inside the WA76-D use the exact same spec data and materials used by Reichenbach Engineering in the original vintage designs known for delivering rich analog tone to any signal chain.
Premium Components & Accurate D-style Circuitry:
WA76-D uses premium ceramic & electrolytic capacitors, metal film resistors, and a revised preamp stage, improving the linear response of the FET. These key components complete a circuit that cuts no corners in delivering an authentic "cleaner, low noise" 76-style compression experience.
Hand-Tested In Austin, TX:
Like all Warm Audio gear, WA76-D is meticulously hand-tested and inspected by trained technicians with a passion for making music in Austin, TX USA.
Tech Specs
- 100% Analog Discrete FET Compressor
- Faithful Recreation Of The Vintage "Rev-D" FET Compressor With Added Recording Features
- VU Meter Options: Gain Reduction | +8dB Output | +4dB Output | "Off" Powers off unit
- 100-230v IEC Inlet Universal Power Supply
- Class-A Line-Level Output Amplifier
- 100% Discrete Audio Signal Path Using 600Ω Input Impedance Attenuator
- Selectable 10kΩ Input Impedance To Better Match Modern Audio Interface Specifications
- 100% Dry-Wet Mix Control
- Variable Sidechain High Pass Filter: 30 - 300Hz, 12dB/Octave
- ¼" Stereo Link & External Sidechain Access
- Active Bypass For Running Unit As Line Amplifier & True Bypass Option For A/B Comparisons
- 2U 19″ Rackmount Chassis
- Utilizes Premium O-12 Input & 5002 Output Transformers From CineMag USA
- Vintage-Spec Attack & Release: Attack = 20 µS - 800 | Release: 50 mS - 1.1 Second
- "All-Buttons-In" Setting For Experimental & Hard-Limiter Tones
- Frequency Response: ± 1 dB 20 Hz - 20 kHz
- Balanced XLR & TRS Inputs & Outputs
- Total Amplifier Gain: 53dB
- Signal-To-Noise Ratio (SNR): 86dB |
- Total Harmonic Distortion (THD): -64dB (at -8dBu)
